Working Voltage Range

DC:  6V-24V

Rating Power

6V:  0-50W/12V:  0-50W/24V:  0-70W

Static Water Head

0-14 M

Static Flow Rate

0-30 L/min

Lifespan

Continuous operation≤24hrs, under normal working surrounding >20000hrs

Working Environment

Liquid: From weak acid to weak base, workable both on land and in water (Submergible)

Max Noise

Under normal working status, 1M distance over test instrument <50dB

Max Working Temperature

Under normal surroundings, fluid medium temperature ≤70℃

Application

High building water supply, Garden sprinklers, irrigation, etc.

Size

IP Grade

Inlet

Outlet

Remarks

Length

(mm）

Width（mm）

Height（mm）

OD

ID

（mm）

OD

ID

（mm）

Inlet and outlet with standard thread

63

63

145

IP68

G1/2” Standard pipe thread

φ25

G1/2” Standard pipe thread

φ25
