Working Voltage Range

DC: 6-24V

Rating Power

6V: 0-17W / 12V: 0-17W / 24V: 0-25W

Static Water Head

0-6 M

Static Flow Rate

0-12 L/min

Lifespan

Continuous operation≤24hrs, under normal working surrounding >20000Hr

Working Environment

Liquid: From weak acid to weak base, workable on land (Non submersible)

Max Noise

Under normal working status, 1M distance over test instrument <40dB

Max Working Temperature

Under normal surroundings, fluid medium temperature≤90℃

Application

solar water heater, hot water shower, Hot shower,

solar water circulation system, Small fountain, Aquarium, etc.

Size

IP Grade

Inlet

Outlet

Remark

Length（mm）

Width（mm）

Height（mm）

OD（inch）

ID（mm）

OD（inch）

ID（mm）

Inlet and outlet with forward spinning Screw pipe thread

96

48

90

IP67

G1/2〞Standard pipe thread

φ13

G1/2〞Standard pipe thread

φ13
