| Model | ZL25-07 | ||||||||
| Working Voltage Range | DC：4.5-12V | ||||||||
| Rating Power | 4.5V：0.5-2W / 6V：1-3W / 12V：2-3W | ||||||||
| Maximum Static Water Head | 0.4-1.8M | ||||||||
| Maximum Static flow rate | 0.6-1.8Litre / minute | ||||||||
| Lifespan | Continuous operation under normal working condition ≤ 24 hours, service life＞20000hour | ||||||||
| Working Environment | PH value：Weak acid, neutral, weak base. Amphibious use | ||||||||
| Max Noise | Under normal working condition, the water pump is 1m away from the tester＜35Decibel | ||||||||
| Max Working Temperature | Under normal temperature environment, the temperature of the aqueous medium≤75℃ | ||||||||
| Application | Water circulation system, desktop fountain, aquarium, foot bath, small medical equipment, etc | ||||||||
| Size | IP Grade | Inlet | Outlet | Remarks | |||||
| Length （mm） | Width （mm） | Height （mm） | OD （mm） | ID （mm） | OD （mm） | ID （mm） | Inlet and outlet with anti slip strip | ||
| 42 | 41 | 42 | IP68 | φ9.5 | φ6.5 | φ9.5 | φ6.5 | ||
Remark: It’s for reference only, the one based on the customer’s endorsement demands shall prevail!
